Diameter m6 |
Range
of Diameter |
Cutting
Edge Length |
Overall
Length |
| Over |
Upto and including |
3.0
-
3.5
4.0
4.5
5.0 |
-
3.00
3.35
3.75
4.25
4.75 |
-
3.35
3.75
4.25
4.75
5.30 |
31
33
35
38
41
44 |
62
66
71
76
81
87 |
5.5
6.0 |
5.30 |
6.00 |
47 |
93 |
-
7.0
8.0
9.0
10.0
11.0 |
6.00
6.70
7.50
8.50
9.50
10.60 |
6.70
7.50
8.50
9.50
10.60
11.80 |
50
54
58
62
66
71 |
100
107
115
124
133
142 |
12.0
13.0 |
11.80 |
13.20 |
76 |
152 |
|
|
|
Diameter m6 |
Range
of Diameter |
Cutting
Edge Length |
Overall
Length |
| Over |
Upto and including |
14.0
15.0 |
13.20 |
15.00 |
81 |
163 |
16.0
17.0 |
15.00 |
17.00 |
87 |
175 |
18.0
19.0 |
17.00 |
19.00 |
93 |
188 |
20.0
21.0 |
19.00 |
21.20 |
100 |
201 |
22.0
23.0 |
21.20 |
23.60 |
107 |
215 |
24.0
25.0
26.0 |
23.60 |
26.50 |
115 |
231 |
27.0
28.0
30.0 |
26.50 |
30.00 |
124 |
247 |
| 32.0 |
30.00 |
33.50 |
133 |
265 |
|
