Diameter
+ 0.045"
- 0.000" |
Diameter of Circle |
Bore
+ 0.00075"
+ 0.00025" |
Width
+ 0.010"
- 0.000" |
|
2.1/4 |
1/8, 3/16, 1/4 |
1 |
5/16, 3/8, 1/2 |
|
2.1/2 |
5/16, 3/8, 7/16, 1/2 |
1 |
5/8, 3/4, 7/8, 1 |
|
2.3/4 |
9/16, 5/8 |
1 |
1.3/16 |
|
3 |
11/16, 3/4 |
1 |
1.3/8 |
|
|
Diameter
+ 0.045"
- 0.000" |
Diameter of Circle |
Bore
+ 0.00075"
+ 0.00025" |
Width
+ 0.010"
- 0.000" |
| 3.1/4 |
13/16,
7/8 |
1 |
1.9/16 |
| 3.1/2 |
15/16, 1 |
1 |
1.3/4 |
| 4 |
1.1/8,
1.1/4 |
1.1/4 |
1.15/16,
2.1/8 |
| 4.1/4 |
1.3/8,
1.1/2 |
1.1/4 |
2.5/16,
2.1/2 |
|
